Rapid® Lift

High Performance Fast Action Door

RAPIDLIFT® Plus is a tough, high-speed door built for maximum performance, durability, and efficiency. Featuring a solid steel frame construction, whisper-quiet operation, and efficient perimeter sealing, it reduces energy consumption and improves environmental control.

Key Features
High Speed
Insulated
Thermal
Sensors Safety
Specifications Summary
Feature Rapidlift
Application External
Max Width 7000mm
Max Height (model 300> 8mtr/model 400>12mtr) 8000mm
Opening Speed up to 2.0m/sec
Top Roll Galvanised Steel
Curtain
  • 900gsm Vinyl
  • Vision Panel – Optional
Door Frame
  • Galvanised
  • Powdercoated – Optional
Wind lock System Full width wind bars
Wind Load Rating Gusts>120klm/hr (Class 3 EU)
Drive System GFA Safedrive IP65-415V Three Phase
Control System
  • GFA TS971 Logic Control IP65 – Standard
  • GFA TS971-XL Logic Control IP65 -Optional
Safety
  • Dual Door-line PE Beam – Standard
  • Light curtain (1800mm active height) – Optional
  • Safedrive intergrated safety brake – Standard
  • Emergency Stop button – Standard
  • Manual Chain over-ride – Standard
  • Manual Crank Handle Override – Optional
Applications Warehouses, logistics hubs, manufacturing, commercial sites, Airport Hanger, Mining, Armed Forces
Additional notes
  • Curtain wear tabs available
  • Galvanised guide with integrated seal
  • Multiple window options
  • Powered by German drive technology
